Enclosure Home Page|Industrial Enclosures|Enclosure Accessories


D, K & KF Series Accessories: Black Nylon Liquid Tight Nylon Strain Relief Fittings
IP 68, Type NEMA 4x & 6 - Approvals: VDE, UL, CSA, CE

Black Nylon Liquid Tight Nylon Strain Relief Fittings, IP 68, Type NEMA 4x & 6 - Approvals: VDE, UL, CSA, CEEnlarge Picture Black Nylon Liquid Tight Nylon Strain Relief Fittings, IP 68, Type NEMA 4x & 6 - Approvals: VDE, UL, CSA, CE

Black Part Number Thread Cable Range: Inches (mm) Included
CD12MA-BK-N CD12MA-BK-N M12 .11 - .26 (3 - 6.5) Locking Nut
CD12MR-BK-N CD12MR-BK-N M12 .08 - .20 (2 - 5) Locking Nut
CD16MA-BK-N CD16MA-BK-N M16 .16 - .31 (4 - 8) Locking Nut
CD16MR-BK-N CD16MR-BK-N M16 .08 - .24 (2 - 6) Locking Nut
CD17MA-BK-N CD17MA-BK-N M16 .20 - .39 (5 - 10) Locking Nut
CD17MR-BK-N CD17MR-BK-N M16 .11 - .28 (3 - 7) Locking Nut
CD20MA-BK-N CD20MA-BK-N M20 .24 - .47 (6.0 - 12.0) Locking Nut
CD20MR-BK-N CD20MR-BK-N M20 .20 - .35 (5.0 - 9.0) Locking Nut
CD22MA-BK-N CD22MA-BK-N M20 .39 - .55 (10.0 - 14.0) Locking Nut
CD22MR-BK-N CD22MR-BK-N M20 .28 - .43 (7.0 - 12.0) Locking Nut
CD25MA-BK-N CD25MA-BK-N M25 .51 - .71 (13.0 - 18.0) Locking Nut
CD25MR-BK-N CD25MR-BK-N M25 .35 - .63 (9.0 - 16.0) Locking Nut
CD32MA-BK-N CD32MA-BK-N M32 .71 - .98 (18.0 - 25.0) Locking Nut
CD32MR-BK-N CD32MR-BK-N M32 .51 - .79 (13.0 - 20.0) Locking Nut
CD40MA-BK-N CD40MA-BK-N M40 .86 - 1.26 (22.0 - 32.0) Locking Nut
CD40MR-BK-N CD40MR-BK-N M40 .79 - 1.02 (20.0 - 26.0) Locking Nut
CD50MA-BK-N CD50MA-BK-N M50 1.26 - 1.50 (32.0 - 38.0) Locking Nut
CD50MR-BK-N CD50MR-BK-N M50 .98 - 1.22 (25.0 - 31.0) Locking Nut
CD63MA-BK-N CD63MA-BK-N M63 1.46 - 1.73 (37.0 - 44.0) Locking Nut
CD63MR-BK-N CD63MR-BK-N M63 1.14 - 1.38 (29.0 - 35.0) Locking Nut
